Seho

PowerWave N2

PowerWave N2
conveyor width 400 mm
max. assembly height 90 mm
stainless steel nitrogen tunnel
energy efficient tunnel insulation
high precision CAN bus motors

number of conveyor segments 2
conveyor angle 7°
ATS spray fluxer with HVLP technology
spray width automatically defined with adjusted conveyor width

modular construction with a module length of 300 mm each
total length of preheat area 1800 mm
power rating solder pot 9 kW
sectorial soldering
solder level control

pass-through direction from left to right

number of preheat zones 6
power rating IR preheat module 3.00 kW
power rating convection preheat module 9.60 kW
power rating quartz preheat module 3.75 kW
composit coating for processing of lead-free alloys
automatic solder bar supply

microprocessor control with touch display
board dimensions programmable
pass-through control
throughput optimization with separately controllable conveyor segments
machine and process data logging

communication interface (SMEMA)

dimensions l x w x h 4374 x 1625 x 1410 mm / 172.18 x 63.98 x 55.49"
weight, approx. 1500 kg
nitrogen supply to be provided onsite

incl. PCP Frame handling in front of and behind the PowerWave N2
